Multilayer PCB
MOKO Technology specializes in manufacturing kinds of multilayer PCB, from double-sided PCBs to 3-layer, 10-layer, and up to 50-layer PCBs.
What Is Multilayer PCB
A Multilayer PCB (Printed Circuit Board) is a type of circuit board that has multiple layers of conductive material and insulation layers sandwiched together to form a complex circuitry design. MOKO Technology, as a leading PCB manufacturer in China, has extensive experience and expertise in multi-layer PCB fabrication. We provide custom-tailored solutions for customers in different industries to meet their specific needs, we can fabricate 3 layer PCB, 4 Layer PCB, 8 Layer PCB, 10 Layer PCB, 12 Layer PCB, 16 Layer PCB, 20 Layer PCB…

Why Choose MOKO

High-Quality Standards
We have a stringent quality control process to ensure that each circuit board is inspected before delivery. We are certified with ISO9001, ISO13485, RoHS, UL, etc.

Short Lead Time
MOKO applies advanced fabrication technologies and machines to improve productivity efficiently, we can deliver multiple PCB with fast turnaround times.

Unparalleled Expertise
Engaging in PCB manufacturing for nearly 20 years, we have all technologies and expertise required to manufacture high-quality PCBs.

Competitive Price
Our in-house PCB manufacturing service enables us to better control costs and quality, providing customers with competitive prices.
Advantages of Multilayer PCB
- Increase Functionality: Multiple layers of boards allow us to fit more components and circuitry on the board, which can increase the functionality and capabilities of circuit boards efficiently.
- Reduced Size: The layered design of a multi-layer PCB is smaller than other PCBs with the same function, because the laminated layers can save a lot of board space.
- Lightweight: The layered configuration of multi-layer PCB can eliminate the need for connectors for separate PCBs, so as to reduce the overall weight of the board.
- High Durability: Multi-layer PCBs use multiple layers of insulation between circuit layers, bonding them together with adhesives and protective materials, which increases their durability.
Application of Multilayer PCB

Consumer Electronics

Industrial Controls

Medical Equipment

Defense & aerospace Systems
Multilayer PCB Capability Overview
Layer
3 - 50 layer
Material
FR-4, CEM-1, CEM-3, High TG, FR4 Halogen Free, FR-1, FR-2, Aluminum
Board Thickness
0.2mm – 7mm
Max. finished board side
500mm * 500mm
Min. drilled hole size
0.25mm
min. line spacing
0.075mm (3mil)
Surface Finish/Treatment
HALS/HALS lead free, Chemical tin, Chemical Gold, Immersion gold Immersion
Copper Thickness
0.5 – 4.0 oz
Solder Mask Color
Black / White/ Green / Blue / Yellow / Red
Hole Tolerance
PTH: ±0.075, NTPH: ±0.05
Our Proven Projects

Multilayer Flexible PCB

Ceramic Multi-layer PCB

HDI Multilayer PCB
